1,400 m³ Largemouth Bass RAS Project
- Project Type
- Commercial RAS Project
- Water Type
- Freshwater
- Project Status
- Operational
- System Water Volume
- 1,400 m³
- Culture Tanks
- 25
- Culture Tank Size
- Ø6 m × 1.5 m
Project Overview
Located in Midong, Urumqi, Xinjiang, China, this commercial freshwater recirculating aquaculture project is used for largemouth bass grow-out. The system has a water volume of 1,400 m³ and 25 culture tanks, each measuring Ø6 m × 1.5 m. The project is operational.
YUTANK’s scope covered system design, main equipment manufacturing, on-site installation and commissioning. The system combines mechanical filtration, protein separation, biological treatment, degassing, oxygenation, disinfection and aeration.
Related technical guide: Moving Bed Biofilm Reactor Technology Explained. Another project for this species: 4,900 m³ Largemouth Bass RAS Project.
Explore RAS Solutions
System Configuration
- Aquaculture TanksQuantity: 25
- Drum FiltersQuantity: 5
- Protein SkimmersQuantity: 5
- Degassing TowersQuantity: 5
- Oxygen ConesQuantity: 5
- Oxygen GeneratorsQuantity: 2
- Ozone GeneratorsQuantity: 2
- MBBR Biofilter TankQuantity: 5
- UV SterilizersQuantity: 5
- Roots BlowersQuantity: 5
- Liquid Oxygen TanksQuantity: 2
