720 m³ Eel RAS Project
- Project Type
- RAS Retrofit
- Water Type
- Freshwater
- Project Status
- Operational
- System Water Volume
- 720 m³
- Culture Tanks
- 18
- Culture Tank Size
- Ø6 m × 1.5 m
Project Overview
Located in Shaxian, Sanming, Fujian, China, this freshwater recirculating aquaculture project is used for eel grow-out as part of a farm retrofit. The system has a water volume of 720 m³ and 18 culture tanks, each measuring Ø6 m × 1.5 m. The project is operational.
YUTANK’s scope covered system design, main equipment manufacturing, on-site installation and commissioning. The system combines mechanical filtration, protein separation, biological treatment, degassing, oxygenation, disinfection and aeration.
Related technical guide: How to Select RAS Equipment for a Commercial Fish Farm. Another project for this species: 240 m³ Eel RAS Project.
Explore RAS Solutions
System Configuration
- Aquaculture TanksQuantity: 18
- Drum FiltersQuantity: 6
- Protein SkimmersQuantity: 4
- Degassing TowersQuantity: 2
- Oxygen ConesQuantity: 4
- Oxygen GeneratorsQuantity: 2
- Ozone GeneratorsQuantity: 2
- MBBR Biofilter TankQuantity: 8
- Biological Filter Media
- UV SterilizersQuantity: 4
- Roots BlowersQuantity: 4
- ReservoirsQuantity: 4
