650 m³ Mandarin Fish RAS Project
- Project Type
- Commercial RAS Project
- Water Type
- Freshwater
- Project Status
- Operational
- System Water Volume
- 650 m³
- Culture Tanks
- 10
- Culture Tank Size
- Ø8 m × 1.5 m
Project Overview
Located in Yiyang, Hunan, China, this freshwater recirculating aquaculture project is used for mandarin fish grow-out. The system has a water volume of 650 m³ and 10 culture tanks, each measuring Ø8 m × 1.5 m. The project is operational.
YUTANK’s scope covered system design, main equipment manufacturing, on-site installation, commissioning, system operation and maintenance. The system combines mechanical filtration, protein separation, biological treatment, degassing, oxygenation, disinfection and aeration.
Related technical guide: How to Select RAS Equipment for a Commercial Fish Farm. Another project for this species: 910 m³ Mandarin Fish RAS Project.
Explore RAS Solutions
System Configuration
- Aquaculture TanksQuantity: 10
- Drum FiltersQuantity: 2
- Protein SkimmersQuantity: 2
- Degassing TowersQuantity: 2
- Oxygen ConesQuantity: 2
- Oxygen GeneratorsQuantity: 1
- Ozone GeneratorsQuantity: 1
- MBBR Biofilter TankQuantity: 4
- Biological Filter Media
- UV SterilizersQuantity: 2
- Roots BlowersQuantity: 2
- ReservoirsQuantity: 2
Operation & Maintenance Support
YUTANK’s confirmed scope included operation and maintenance of the RAS equipment and treatment processes.
